4 post mobile column ATH RG7.5-4
electro-hydraulic400Vfor trucks

4 post mobile column
4 post mobile column
4 post mobile column
4 post mobile column
Add to favorites
Compare this product


Characteristics

Type
4 post
Operation
electro-hydraulic
Voltage
400V
Applications
for trucks
Lifting height

Min.: 0 mm (0 in)

Max.: 1,760 mm (69.291 in)

Description

Mobile column lift ATH RG7.5-4 Mobile column lift for trucks with 4 mobile columns, rated load capacity per column 7500 kg Description Highest quality: High-precision manufacturing by laser cutting and robotic welding Long-lasting technology: Robust and less sensitive drive, almost maintenance-free Flexible use: 4 mobile columns can be flexibly positioned due to long connecting cables, can easily be extended to a 6-column-system Easy handling: With the hand hydraulic jack-lift, the columns can be moved in an easy and secure way High operating comfort: Control unit on every column, lifting and lowering with push button control Great variability: The control can be switched from one to all-column lifting Precise lifting and lowering: Lifting mechanism with wear-free trapezoidal screw drive, self-locking bronze lifting nut and low-maintenance geared motor Maximum security: Safety nut if the support nut breaks Modern design: Powder-coated lift in attractive anthracite gray Perfect lift for trucks and busses Optional: Adapter for smaller wheels (item number: 710020) Optional: Mobil support frame (item number: 710050)
