Helical-toothed rack and pinion UHPR series

precisiongroundsteel

Q3 - Quality Class 3 Technical Datas: Heat-treatable steel according ATLANTA-Standard Teeth hardened with the ATLANTA high performance hardening process and ground Ground on all sides after hardening Signed with effective total pitch error (20°) Total pitch error GTf 1000 ≤ 0,012mm 19°31'42" helical and straight tooth system Module 5 to 12 Length up to 1000mm Max. feed force per pinion contact up to 409,0 kN Q5 - Quality Class 5 StrongLine Technical Datas: Case hardening steel according ATLANTA-Standard Teeth case hardened and ground Ground on all sides after hardening Signed with effective total pitch error (20°C) Total pitch error GTf/1000 ≤ 0,026mm 19°31'42" helical and straight tooth system Module 3 to 6 Length 1000 mm Max. feed force per pinion contact up to 131,5 kN
