AC UPS AESA ECO

single-phasewith LCD displayemergency

Overview
Central power supply for emergency lighting (central battery system) with a microprocessor-controlled LCD for monitoring current and voltage parameters. Wall-mount design for 230VAC networks. Integrated battery test and deep-discharge protection provide controlled battery management. Standard autonomy: 1 hour.

BC panic option
Option enabling forced permanent mode of emergency lighting (panic) when combined with a permanent central source. The unit can be returned to continuous operation manually or automatically upon restoration of the mains supply.

Remote control panel option
Alarm report box option with 4 free relay contacts and front-panel LEDs for remote signaling and status indication.

Specifications

• Standards: EN50171 / NFC 71815
• Mounting: Wall mount
• Nominal voltage: 230VAC
• Power range: 250VA to 1000VA
• Battery protection: Deep-discharge limiting device
• Display: Graphic alphanumeric display controlled by microprocessor
• Integrated battery test
• Autonomy: 1 hour (standard)
• Start protection: 4 protected starts by HPC fuse
• Options: BC panic; Remote control panel (alarm report box with 4 free relay contacts and front LEDs)
