The AvaSpec-ULS2048x64TEC-EVO is an updated version of our AvaSpec-ULS2048x64TEC spectrometer, with improved electronics and cooling.
This instrument enhances the SensLine series with its cooled, back-thinned detector. The back-thinned detector has a high level of sensitivity in the UV and IR region. The 64-pixel height (0.89 mm) enables catching as many photons as possible while the cooling enables long integration times up to 120 seconds with low-noise levels.
The instrument features Peltier cooling device integrated into our exclusive ultra-low stray-light optical bench, which can reduce the temperature of the CCD chip to -30°C against ambient, significantly improving the dark baseline and PRNU level. The detector cooling also reduces the dark noise by a factor of 2-3.
The AvaSpec-ULS2048x64TEC-EVO uses a special low-noise version of the 2048×64 detector with integrated cooling.
All the features mentioned above make this instrument ideally suited for measuring low-light applications, such as fluorescence or low-light Raman measurements.
Optimum flexibility is guaranteed with the replaceable slit, making the instrument suitable for various kinds of applications.
Optical bench - ULS symmetrical Czerny-Turner, 75 mm focal length
Resolution - 0.09-20 nm, depending on configuration, see resolution tab
Stray light - <1%, depending on grating
Sensitivity in counts/µW per ms integration time - 300,000
Detector - CCD linear array, 2048×64 pixels, low noise
Temperature cooled CCD - Max. ΔT = -30°C versus ambient. Optimal setting: 5°C
1 stage Peltier cooling internal power supply@ΔT=-35° - 5 VDC, 3.0 A
