Hydrostatic level sensor LMP 331i
for waterfor oilfor wastewater

hydrostatic level sensor
hydrostatic level sensor
Add to favorites
Compare this product


Characteristics

Technology
hydrostatic
Medium
for water, for oil, for wastewater
Interface
analog
Applications
for fill monitoring, for corrosive environments, for hazardous areas
Other characteristics
high-precision, stainless steel, programmable, chemical-resistant, ATEX, IP65, IECEx, temperature-compensated, PVC, clamp-on, IP67, IP68
Level range

Max.: 250 m
(820'02" )

Min.: 2 m
(6'06" )

Process pressure

Max.: 40 bar
(580.15 psi)

Min.: 0 bar
(0 psi)

Process temperature

Max.: 125 °C
(257 °F)

Min.: -20 °C
(-4 °F)

Description

The precision screw-in transmitter LMP 331i demonstrate the further development of our industrial pressure transmitters. The signal processing of sensor signal is done by digital electronics with 16-bit analogue digital converter. Consequently it is possible to conduct an active compensation and the transmitters with excellent maesurements and exceptionally attractive price to offer on the market. Nominal pressure - from 0 ... 400 mbar up to 0 ... 40 bar Output signal - 2-wire: 4 ... 20 mA - 3-wire: 0 … 10 V - others on request Product characteristics - thermal error in compensated range -20 ... 80 °C: 0.2 % FSO TC 0.02 % FSO / 10K - Turn-Down 1:10 - communication interface for adjusting offset, span and damping Optional versions - IS-versions - Ex ia = intrinsically safe for gases and dusts - adjustment of nominal pressure range (factory-provided) Preferred areas of use are - Chemical / petrochemical industry - Environmental engineering (water/sewage / recycling)
