2-axis tilt switch ISX/2H60DS-0,3

2 AXES INCLINATION SWITCH (± 60°) with 2 on/off static outputs Insensitive to shock and vibrations • Self teaching of zero position and threshold • Low power • High thermal stability • General features: These sensors give two NPN normally open outputs which connect to the negative power supply when the preset thresholds of the X and Y axes are exceeded. The sensor is insensitive to shocks and vibrations and the absolute zero is factory calibrated to ground level. The thresholds can be factory preset at specified values. If not otherwise specified both the thresholds are preset at ± 5° for both the axes. Both the thresholds and the zero position can be modified in the field. Applications: • Inclination control on lifting systems • Vehicle inclination monitoring • Feedback sensor on self-levelling systems Technical data: • Measuring range: ± 60° • Resolution: 0,2° • Supply voltage: 8 ÷ 40 Vcc • No load supply current: ≤ 10 mA • Output: NPN n.o. open collector • Max thermal drift of switching point: 0,03° / °C • Max output current: 200 mA • Max response time: 0,1 sec • Cross axis sensitivity: < ± 2% • Maximum survival shock: 1000 g • Working temperature: - 20 ÷ + 70°C • Storage temperature: - 20 + 100°C • Degree of ingress protection: IP67 • LED indications: Green = supply voltage Yellow = threshold exceeding • Shock and vibration resistance according to EN60068-2-27 EN60068-2-6 • Electromagnetic compatibility (EMC) according to EN61000-6-2/-4 Materials: • Cable: PVC CEI 20 - 22 II; 90° C • Housing: plastic • Connector locking nut: nickel plated brass
