Chain load binder G80 series

manual

Chain lashings secure the load by tensioning steel chains. BEGNI Group offers a wide range of products for chain lashing. Ratchet load binders are made in a single body: they are not assembled with screws or bolts (easy to lose). The bearing elements (eyes and hooks) are in forged steel. The gear and the crack spring are rust resistant. The shortening hooks are equipped with a safety mechanism. ■ Compliant to EN12195-3. ■ High tensile strength. ■ Very low elongation at the lashing capacity (LC). ■ Ratchet load binders are made in a single body: they are not assembled with screws or bolts (easy to lose). ■ The bearing elements (eyes and hooks) are in forged steel. ■ The gear and the crack spring are rust resistant. ■ The shortening hooks are equipped with a safety mechanism. ■ Alloy steel grade 80, red painted. ■ Diameter: up to 16 mm. ■ Lashing capacity (LC) up to 16000 daN. ■ STF: up to 3000 daN. ■ Working and storing temperatures: -20 ÷ 200 °C. ■ Compliant to EN12195-3. 4 types: G80RLB08 ■ Diameter= 8 mm ■ LC= 4000 daN ■ STF= 1900 daN G80RLB10 ■ Diameter=10 mm ■ LC= 6300 daN ■ STF= 1900 daN G80RLB13 ■ Diameter=13 mm ■ LC= 10000 daN ■ STF= 3000 daN G80RLB16 ■ Diameter=16 mm ■ LC= 16000 daN ■ STF= 3000 daN ——– Technical terms (according to EN12195-3) LC: lashing capacity (for diagonal lashing). STF: tension applied to the chain (for frictional lashing). Before using the products, carefully read the instructions for safe use. For further information, please contact us: our sales technicians will indicate the most suitable products for your applications.
