Coating thickness gauge DC-3000 serieswallfor pipesportable
Add to favorites
Compare this product
Characteristics
- Applications
- coating, wall, for pipes
- Type
- portable, handheld
- Technology
- digital display, ultrasonic
- Measuring range
Min.: 0.65 mm
(0.03 in)Max.: 400 mm
(15.75 in)
Description
Features:
1. Be Capable of reading wall thickness thru coatings and paint without affecting the measurement
2. Auto probe zero calibration, Auto Probe identify
3. Measuring range: Thru coating mode: 3-25mm Standard mode:0.65-400mm
4. Display resolution: 0.01mm or 0.001 inch
5. 5 MHz,7.5MHz, 10MHz, 2.5MHz transducers are available
6. Accuracy:±0.04mm (when thickness＜9.99mm)
±(0.1% thickness + 0.04)mm (when thickness=10-99.9mm)
±0.3% thickness mm (when thickness＞100mm)
7. USB output, memory 5000 readings with location number(DC-3020)
