Electrical safety tester UNIMET® 400ST

for medical devicesfor electrical equipmentmedical

The lightweight version for mobile applications Intelligent and practice-oriented Safe testing of medical electrical equipment with patient connections, hospital beds, care beds and electrical equipment Easy-to-use Classification help Four operating keys Features Easy and safe to handle Automatic and manual test sequences Data input via keyboard or barcode scanner Visual inspection, functional test and electrical tests 600 data records can be stored Data exchange and storage via UNIData 300 software Compatible with common application programs z. B. visual FM, MT Data and Fundamed Wide variety of interfaces RS-232 connection PS/2-port for scanner and keyboard Centronic connection for the printer Standard accessories Carrier bag of robust design, universal carrying concept Measuring lead with test probe and test terminal 0-modem cable Converter cable USB/RS-232 Data management software UNIData 300 Service Calibration interval 36 months 36-month warranty Software updates for effective application in the future Applications Standard-compliant tests in accordance with: IEC 62353:2007-05 DIN EN 62353 (VDE 0751-1):2008-08 ÖVE/ÖNORM EN 62353:2009-01 DIN VDE 0701-0702:2008-06 ÖVE E8701-1:03-01 The following tests can be performed Protective earth conductor resistance Insulation resistance PE current Equipment leakage current Touch current Applied part leakage current Measurement methods of leakage currents Direct measurement method Differential measurement method Equipment leakage current -alternative measurement
