Hack saw 17-547-VDE

The VDE metal saw 17-547-VDE is a hand saw engineered for safe metal cutting in electrical environments and for professionals requiring VDE-certified insulated tools.

Key features

• Aluminium die-cast frame
• Fully insulated, multi-layer dip insulation (two-layer: red outside / yellow inside) for visible damage detection
• Replaceable HSS (high-speed steel) saw blade
• Hardened toothing
• Overall length: 460 mm
• Weight: 580 g
• Tested and approved for working under voltage up to 1000 V (VDE EN 60900 / IEC 60900)
• Insulation: REACH compliant, phthalate free

Technical description
The tool features a two-layer visible safety insulation (red outer layer, yellow inner layer) enabling immediate visual detection of any damage to the outer insulation. Each tool is individually tested according to VDE EN 60900 / IEC 60900 and approved for live working up to 1000 volts. The saw accepts a replaceable HSS blade with hardened teeth for metal cutting. Insulation materials are REACH compliant and phthalate free.

Characteristics / Technical specifications

• Model: 17-547-VDE
• Product type: VDE metal saw
• Saw blade length: 300 mm
• Saw blade material: HSS (replaceable)
• Toothing: hardened
• Frame material: aluminium die-cast
• Overall length: 460 mm
• Weight: 580 g
• Insulation type: multi-layer dip insulation, two-colour (red/yellow)
• Standards / Testing: VDE EN 60900 / IEC 60900 (piece-by-piece tested)
• Voltage rating: approved for working under voltage up to 1000 V
• Material compliance: REACH compliant, phthalate free
