Circular saw CPO series

for metalsfor tubesfor profiles

Overview
The Bewo CPO-315 is a manually operated metal circular saw for cutting profiles and tubes in workshops and light-industrial environments. It uses a self-centring clamping jaw system to ensure central positioning, reduce burr formation and limit blade wear. Options include a pneumatic clamp (PK) for batch work and a mitre lock for angular cuts.

Key features

• Self-centring clamping jaws that clamp both sides of the workpiece for consistent central positioning.
• Cutting with minimal burr formation due to precise clamping and positioning.
• Optional mitre lock for left and right mitre cuts.
• Pneumatic clamp version Bewo CPO-315 PK available for series production.
• Robust saw motor and drive with tight tolerances designed for long service life and low maintenance.
• Available in low-speed (LT) and high-speed (HT) configurations to suit different materials.

Models and variants
The Bewo CPO range includes the Bewo CPO-315 (manual) and the Bewo CPO-315 PK (with pneumatic clamp). Both are offered in LT and HT speed variants.

Speeds and materials

• LT versions (low speed): 18.5 and 37 m/min — suitable for stainless steel and structural steel.
• HT versions (high speed): 37 and 74 m/min — suitable for structural steel and non-ferrous metals.

Accessories and adjustments

• Diagonal clamping
• Length stop / length adjustment
• Angle adjustment and mitre stop

Technical specifications

• Series: CPO
• Model: CPO-315
• Type: manual metal circular saw
• Clamping: self-centring clamping jaws (option PK: pneumatic clamp)
• Options: mitre lock (left/right), pneumatic clamp (PK)
• Speeds LT: 18.5 and 37 m/min; HT: 37 and 74 m/min
• Suitable materials: stainless steel, structural steel, non-ferrous metals (depending on version)
• Primary benefits: reduced burr formation, reduced blade wear, low maintenance, long service life
