Hydraulic orbital tube-cutting machine SCF Alpha

steelautomatic

Overview
The SCF-Alpha is the essential version of a standalone automatic sawing machine for steel tubes. Designed for simplicity and reliability, it provides a stable, efficient cutting process for standard applications while keeping investment and operating costs low. Typical supply includes bundle loader, gripper feeder and a single-machine saw head with a 3 m outfeed table.

Key features

• Fully automatic steel tube cutting including bundle loader and gripper feeder
• Single-machine saw head with 3 m outfeed table
• Selected PLC and components for proven, cost-effective operation

Applications / Suitable materials

• Seamless round, square and rectangular tubes
• Welded precision tubes
• Chrome steel tubes
• Welded cold-drawn tubes
• High-pressure pipes

Performance & use
Used in steel service centres, construction, furniture production and similar sectors. Well suited for small batches and standard production runs using universal tooling.

Performance highlights

• Maximum output: up to 1,500 pieces per hour (indicative)
• Working range (round tubes): Ø 15–60 mm; example square profile: 45×45 mm
• Number of tools required: 1

Advantages

• Flexible length and diameter adjustment
• Equipped with essential components only (no unnecessary options)
• Optimised for sawing tasks with low running costs

Technical specifications

• Brand: BEWO Cutting Systems
• Model: SCF-Alpha
• Multiple cut min. – max.: 1 p/cut
• Max. saw blade diameter: 400 mm
• Sawing servo motor: 3 kW
• Cutting speed: 20–250 m/min
• Transport system: gripper feed, servo
• Clamping force: hydraulic
• Clamping setup: one clamp
• Accuracy Ø < 25 mm: 0.4 mm
• Material type: steel
• Minimum starting length: 3,700 mm
• Maximum starting length: 7,000 mm
• Transport weight: 40 kg
• Bundle loader capacity: 3,000 kg
• Bundle Ø: 650 mm
• Bundle loader: automatic
• Round tube range Ø: 15–60 mm
• Square profile min.: 12×12 mm
• Max. square profile: 80×80 mm
• Minimum wall thickness: 1 mm
• Minimum cutting length: 10 mm
• Max. product length: 3,000 mm
• Product weight (example): 15 kg
• Indicative max. throughput: 1,200–1,500 p/h depending on configuration
