Carbon steel orbital tube-cutting machine SCF Sigma

coldhigh-speedCNC

Product overview
The SCF Sigma is a fully automated tube cutting saw engineered for continuous high-volume production. It performs multiple simultaneous cuts (up to 6 tubes per cut) with servo-controlled blade speed and gripper feed, minimising cycle time and cost per cut while ensuring repeatable dimensional accuracy.

Key features

• Multiple simultaneous cutting: up to 6 tubes per cut
• Maximum output: up to 12,000 pieces/hour (project dependent)
• Accuracy: 0.1 mm (for Ø < 25 mm)
• Saw blade max diameter: 400 mm; saw motor: 9 kW
• Gripper stroke: 3,000 mm; transport speed: up to 4 m/s
• Hydraulic multi-clamping and servo gripper feed

Performance and processing
The machine combines intelligent clamping, a powerful saw head and proportional cutting strategies to maximise throughput and extend blade life. Servo regulation of blade rotation and feed ensures short cut times (below one second in optimal conditions) and stable quality in high-volume runs.

Examples of profiles that the SCF Sigma can process

• Seamless round, square and rectangular tubes
• Welded precision tubes; chrome steel and cold-drawn welded tubes
• High-pressure pipes
• Solid bar stock: round, square, rectangular, flat
• Materials: carbon steel, alloy steel, stainless steel, non-ferrous materials

Technical table (selected values for SCF Sigma)
Multiple cut min.–max.: 1–6 p/cut
Max. saw blade diameter: 400 mm
Sawing servo motor: 9 kW
Cutting speed: 20–250 m/min
Transport system: gripper feed, servo
Clamping force: hydraulic
Accuracy Ø < 25 mm: 0.1 mm
Minimum starting length: 3,700 mm — Maximum starting length: 7,350 mm
Transport weight: 50 kg
Bundle loader capacity: 3,000 kg; bundle Ø: 650/850 mm
Round tube range Ø: 15–80 mm (model dependent)
Square profile: 10×10 – 80×80 mm
Rectangular: 15×10 – 85×60 mm
Minimum wall thickness: 0.8 mm
Solid max. Ø: 35 mm
Minimum cutting length: 10 mm (with deburring: 150/100 mm; with washing: 200 mm)
Maximum product length: 6,000 mm
Maximum output reference: 12,000 pieces/hour

Characteristics / technical specifications

• Model: SCF Sigma
• Series: SCF
• Maximum simultaneous tubes per cut: up to 6
• Maximum saw blade diameter: 400 mm
• Sawing servo motor power: 9 kW
• Cutting speed range: 20–250 m/min
• Transport: gripper feed (servo); transport speed: 4 m/s
• Clamping: hydraulic, multiple setup; positioning accuracy: 0.1 mm
• Starting length range: 3,700–7,350 mm; max product length: 6,000 mm
• Bundle loader capacity: 3,000 kg; bundle Ø: 650/850 mm
• Material compatibility: carbon steel, alloy steel, stainless steel, non-ferrous materials
