Paint reciprocator Ransburg RAF

This is an AC motor driven reciprocator that has a simple construction and invertor control with superior constant speed stability. There are two types available; a stroke variable type which can be used for control in units of 10mm, and a stroke fi xed type. For either type, you can chose between 5 different maximum stroke lengths between 1500mm~2500mm, in order to select the length that best matches the painting environment. Features Paint can be automatically controlled and turned ON/OFF according to the shaper of the object. Travelling speed of the applicators can be adjusted within a fi xed scope according to the conveyer speed and condition of coated surface. It has a simple structure and excellent stability in speed because the 3-phase motor is controlled by the inverter. Velocity set up easily can be done on the inverter panel. Also can be controlled with the external equipment as an option. Multifunction Control Unit for reciprocation RCS-1 Flexible velocity setting of applicator. Set-up capability of 99 different coating conditions. Combined control of variable stroke and paint cut. Specifications Model Type - Rafford (RAF Type) Application - Gun / Bell Explosion-proof type Motor - Inverter / 1.5 kW Position detection method - Encoder / Pulse sensor Stroke - Encoder - Variable Pulse sensor - Constant Stroke Control - Encoder - Set up by 10mm Pulse sensor - Constant
