RS-485 converter ICD107A

ModbusrepeaterDIN rail mounted

DIN rail workhorses, three-way isolation and rugged durability in temperature extremes Three-way isolation, 2000-V input/output. Operates from -40 to +85°C. Warranty: 5 Year Double Diamond™ Warranty (Standard) ICD107A: Industrial RS-422/RS-485 DIN Rail Repeater Features optical isolation plus 600 W of surge suppression. Adds 1219.2 metres and another 32 nodes to an RS-485 data circuit. Configure one side as RS-422 and the other side as RS-485 to enable a 4-wire RS-422 device to communicate with a 2-wire RS-485 device. Modbus ASCII or RTU compatible. Automatic Send Data Control eliminates the need for driver software. MED101A: Industrial DIN Rail RS-232/V.24/RS-422/RS-485 Multimode Fibre Driver Enables any two async serial devices to communicate half- or full-duplex over two multimode ST fibres at distances up to 4 kilometres. RS-232/V.24 signals are supported up to 115.2 kbps; RS-422 or RS-485 signals are supported up to 460.8 kbps. Can do fibre ring/RS-485 Multidrop. Modbus ASCII or RTU compatible. Automatic Send Data Control eliminates the need for driver software. Removeable terminal blocks.
