Asynchronous drum motor V SERIES

asynchronous drum motor
asynchronous drum motor
Add to favorites
Compare this product


Characteristics

Motor type
asynchronous
Diameter

Min.: 140 mm
(5.5 in)

Max.: 400 mm
(15.7 in)

Description

V series gear units are three stage, helical-geared hoist drum drive units. Input and output centre distances are as far apart as possible to allow the use of larger drums to achieve longer rope service life. The V series gear units are designed for higher ISO/FEM classes with longer gear face widths compared to other products of a similar size. The housing material is GGG40 spheroid cast iron and gears are made of high quality case-hardened steel. The gearboxes have a solid output shaft with spline according to DIN 5480 and are produced to various dimensions. V series gear units are designed for double-and single-speed brake motors. They are available in five different sizes with a load range from 0.5 to 50 tonnes. • Wide speed range • Load range from 0.5 to 50 tonnes • Designed for double- and single-speed brake motors • Solid output shafts with spline according to DIN5480 • GGG40 spheroid cast iron housings • Power panel can be mounted directly on the drive unit • Suitable for different mounting positions
