Screw vacuum pump COBRA NS 0160 C
dryhigh-performanceanti-corrosion

screw vacuum pump
screw vacuum pump
Add to favorites
Compare this product


Characteristics

Technology
screw
Lubrication
dry
Other characteristics
high-performance, anti-corrosion, low energy consumption
Power

5.5 kW, 6.6 kW (0 hp)

Width

483 mm (19 in)

Length

873 mm (34.37 in)

Height

416 mm (16 in)

Sound level

68 dB

Weight

250 kg (551.2 lb)

Flow rate

135 m³/h, 160 m³/h (4,767.48 ft³/h)

Ultimate vacuum

0.03 mbar (0 psi)

Description

COBRA NS 0070 - 0600 C Advanced Screw Design Efficient: low energy consumption, minimal maintenance, minimized operating costs Robust: high vapour and particle tolerance, anti-corrosion on internal components, inert lubricant High performance: high pumping speed at all inlet pressures Leak-tight design: The COBRA NS is a series of high-performance and robust dry screw vacuum pumps for demanding applications with maximum flexibility and modularity for process changes. These vacuum generators are in use wherever gases and vapours need to be pumped reliably. The proven, completely dry screw vacuum technology allows the COBRA NS to run without operating fluids in the compression chamber. In practice this means no contamination of the pumped medium, and no environmental emissions. In addition, no costs arise for the purchase, replacement and disposal of operating fluids. Maintenance tasks such as oil changes or filter replacement are no longer required or are reduced to a minimum. Vacuum pumps of the COBRA NS series are robust, extremely reliable and highly efficient. They operate efficiently throughout their vacuum range, and deliver constantly high pumping speeds. COBRA NS dry screw vacuum pumps feature dry compression, a specially developed screw profile, and unimpeded gas discharge. The result is a high degree of vapour and particle tolerance. Their design guarantees an even heat distribution over the whole pump stage, reducing thermal stress and increasing service life. The integrated motor makes this vacuum pump series leak-tight. Optimum corrosion resistance is ensured thanks to temperature control and special coatings on the screws.
