diaphragm pressure switch / adjustable / IP65 / IP54
PM series



  • Technology:


  • Other characteristics:

    adjustable, IP65, IP54

  • Process temperature:

    Min.: -5 °C (23 °F)

    Max.: 60 °C (140 °F)

  • Pressure range:

    Min.: 1 bar (14.5 psi)

    Max.: 10 bar (145.04 psi)


The construction of this item includes an adjustable diaphragm, while mounting is possible using a thread-in body. The ports supported are R1/8, G1/4, M5 and tube 4/2, depending on the chosen product series, while the operating pressure has a value of -5 to 60 degrees Celsius.

The operating pressure is between 1 and 10 bar, while the 220V voltage and 100VA maximum power are worth mentioning. The protection class is IP54, while the maximum current supported is 0.5A.
