TIG welder DDA115.320.T-E.01.01 / DDD115.320.T-E.02.01
portableDCinverter

TIG welder
TIG welder
TIG welder
Add to favorites
Compare this product

Characteristics

Technique
TIG
Other characteristics
portable, DC, inverter
Current

Min.: 0 A

Max.: 320 A

265 A

Description

DUTY • TIG DC duty cycle 320 A – 70% • TIG DC output at 100% duty cycle 265 A • Electrode duty cycle 320 A – 60% • Electrode output at 100% duty cycle 245 A INVERTER • Mains voltage 230V±10% • Frequency 50/60Hz • OCV 85 V • Electrode Nominal Power 100% % 9,1 KW • TIG DC Nominal Power 100% 6,8 KW • Electrode arc voltage 20,2 – 32,8 V • TIG arc voltage 10,2 – 22,8 V • Max current 22,5 A • Protective Fuses time lag 20 A • Power factor 0,85 • Degree of protection IP 23 S • Insulation Class F • Working temperature -10°C+40°C • Size (mm) 420x180x265 • Weight (Kg) 16,80 FEATURES • Electrode output range 5 – 320 A • TIG DC output range 5 – 320 A • Hot start Automatic • Arc force on-off option • Antisticking Automatic • Type of arc ignition HF/LIFT ARC • TIG DC control 2/4T - STEP • Base current min. ÷ 80% • Slope up 0-20sec • Slope down 0-20sec • Post gas 0-20sec • End current min. ÷ 80% • Pulser SI / YES • Pulser frequency 1-500 Hz / *1-400 Hz

Catalogs
