Pneumatic tired road roller PT240D

Overview
The CASE PT240D pneumatic tire roller is built for sub-base and asphalt compaction on large-scale road, highway and airport runway projects. It features a 21,380 lb operating weight with ballast adjustable up to 52,910 lb to increase compaction efficiency and reduce required passes. Offset rear tires provide a consistent linear load, while a triple-filtration pump system ensures long service life and uniform water spraying. Operator ergonomics include automotive-style pedals and steering with dual workstations and easy access to service points for faster maintenance.

Walkaround / Visual Tour
Inspect key features and operator-focused design elements: accessible service points, dual operator stations, sprinkler controls and the pressurized water system with filtration.

STANDARD EQUIPMENT

• Fixed ROPS open platform with hand rails
• 4-point lift and tie down provisions
• Brush scrapers on each tire
• Dual operator stations
• Sprinkler system ON/OFF indicator light
• Monitor display panel showing % engine load at current RPM
• Pressurized water system
• Single-stage water filtration
• Watering system drains
• CASE SiteWatch telematics hardware with 5-year advanced data subscription

OPTIONAL EQUIPMENT

• Tiltable scrapers (spring applied)
• Water-tight chassis ballast compartment (460 liters / 122 gallons)
• Edge cutter

WARRANTY

• 1-Year unlimited-hour base limited warranty
• 2-Year / 2,000-Hour extended limited engine warranty
• Purchased protection plans available (up to 6 years / 7,500 hours)

Emissions & Performance
The PT240D meets Tier 4 Final emissions standards while delivering improved compaction quality in fewer passes for both sub-base and asphalt applications.

Additional product notes

• Adjustable ballast and consistent linear load designed to reduce number of passes
• Triple-filtration pump system for longevity and uniform spraying
• Automotive-style pedals and steering for operator familiarity
• Dual operator workstations for enhanced visibility and control
• Easy access to service points for faster maintenance

Specifications

• Model: PT240D
• Operating weight: 21,380 lbs
• Maximum ballast (adjustable): up to 52,910 lbs
• Tire configuration: pneumatic tires with offset rear tires for consistent linear load
• Water system: pressurized system with single-stage filtration and draining provision
• Sprinkler control: ON/OFF indicator
• Monitor: display panel including % engine load at current RPM
• Operator stations: dual workstations, automotive-style controls (pedals and steering)
• Filtration: triple-filtration pump system
• Telematics: CASE SiteWatch hardware included with 5-year advanced data subscription
• Optional ballast compartment capacity: 460 liters (122 gallons) when water-tight chassis ballast option selected
• Warranty: 1-Year unlimited-hour base limited warranty; 2-Year / 2,000-Hour extended limited engine warranty; optional purchased protection plans up to six years / 7,500 hours
