Plastic pipe pipe threading machine F60

semi-automatic

Overview
The F60 is a semi-automatic threading machine designed for high‑volume production of external threads on long bars. The threading head opens automatically at the end of the cycle. Workpieces remain fixed while cutting tools rotate around the bar; a powerful self‑centering pneumatic clamp secures long pieces for safe machining. The mobile carriage runs on ball bearings and is moved by a handwheel for simple, precise positioning.

Main Features

• Engine power: 7.5 kW
• Torque motor: 80 Nm
• Torque on spindle: 1030 Nm
• Clamping diameter range: Ø8 to Ø60

Operation

• Self‑centering pneumatic clamping — maximum clamping force up to 2 tons. Clamp opening/closing coordinated with carriage position. Two sets of V‑shaped clamping jaws. Maximum opening stroke: 24 mm.
• Thread length adjustment via pneumatic abutment internal to the spindle.
• 5.6'' control screen for setting spindle speed according to cutting parameters, diameter and thread pitch.
• Easy mounting and setup of chasers; chasers are resharpenable.
• Working position selectable on the right or left side (to be specified on order).
• Automatic coolant system.
• Motor specification: 7 kW, 6 poles (as stated in operational data).

Strengths

• Durability: Engineered for continuous industrial use and intensive production.
• Simplicity: Manual carriage control and intuitive clamping reduce operator training needs.
• Cost efficiency: Resharpenable chasers lower consumable costs.
• Versatility: Produces cylindrical or conical threads, right‑ or left‑hand, on ribbed bars, stainless steel, aluminium, bronze and plastics.

Documents & Video

• Technical file (PDF) available for the F60 (English).
• Product video available (YouTube).

Technical specifications

• Model: F60
• Machine type: Semi‑automatic traditional threading machine with automatically opening head
• Engine power: 7.5 kW (motor: 7 kW, 6 poles)
• Torque motor: 80 Nm
• Torque on spindle: 1030 Nm
• Clamping diameter range: Ø8 to Ø60
• Maximum clamping force: up to 2 tons (self‑centering pneumatic clamp)
• Maximum clamp opening stroke: 24 mm
• Thread length control: pneumatic abutment internal to spindle
• Control interface: 5.6'' screen for spindle speed and cutting parameter setup
• Mobile carriage: ball bearings, operated by handwheel
• Chasers: easy mounting, resharpenable
• Automatic coolant/watering system
• Working position: right or left configuration (to be defined at order)
• Thread types: cylindrical or conical; right or left threads
• Materials: steel (including ribbed bars), stainless steel, aluminium, bronze, plastic
