Plastic pipe pipe threading machine A33

semi-automatic

Description
The semi-automatic threading machine A33 by Cergil Industry Srl is a compact, mobile unit designed for on-site and workshop external threading up to diameter M30. It features a rotating mandrel with an R33 automatic opening/closing head and an adjustable fixed vice, enabling fast setup and portability while allowing chaser regrinding to reduce tooling costs.

Main features

• Engine power: 3 kW.
• Motor torque: 154 Nm.
• Spindle torque: 590 Nm.
• Closing clamps diameter: Ø8–Ø33.

Operation

• Mobile unit driven by a gearmotor with trapezoidal belt transmission that turns the rotating mandrel equipped with the R33 head.
• Manual movement of the threading unit on recirculating ball sleeves.
• Self-centering manual clamp; pneumatic clamp available as option; V-shaped clamping jaw (option for two V jaws).
• Pneumatic or automatic opening/closing threading head.
• Threading length adjustable inside the mandrel.
• Custom 5" monitor for setting mandrel rotation speed according to cutting parameters, diameter and thread pitch.
• Simplified mounting and setup of chasers; chasers resharpenable.
• Automatic cooling/lubrication system.

Strengths

• Practical: compact dimensions and optional wheels for use on construction sites.
• Simplicity: intuitive operation without special operator skills.
• Cost optimisation: regrindable cutting tools to lower production expenses.
• Versatility: produces cylindrical or conical threads, right- or left-handed; suitable for steel (including ribbed bars), stainless steel, aluminium, bronze and plastic.

Technical specifications

• Model: A33
• Maximum threading diameter: M30
• Engine power: 3 kW
• Motor torque: 154 Nm
• Spindle torque: 590 Nm
• Closing clamps diameter range: Ø8–Ø33
• Threading head: R33 automatic opening/closing head (pneumatic option)
• Vice: fixed and adjustable; self-centering manual clamp (pneumatic optional); V clamping jaw (option for 2 V jaws)
• Drive: gearmotor with trapezoidal belt transmission driving rotating mandrel
• Movement: manual movement on recirculating ball sleeves
• Monitor: custom 5" monitor for mandrel rotation speed setting
• Chasers: resharpenable; simplified mounting and setup; possibility to regrind
• Thread types: cylindrical or conical, right or left
• Materials: steel (including ribbed bars), stainless steel, aluminium, bronze, plastic
• Other: automatic cooling/lubrication; threading length setting inside mandrel
