Plastic pipe pipe threading machine F114

semi-automatic

Main features

• Engine power: 7.5 kW.
• Spindle torque: 2132 Nm.
• Clamping range: Ø33 – Ø114.

Description
Semi-automatic threading machine designed for cutting threads with a head that opens automatically at the end of the operation. Built for intensive industrial production with low operating costs. The workpiece is fixed while the tools rotate around the bar, allowing safe threading on very long pieces thanks to a powerful self-centering pneumatic clamp. The mobile carriage runs on ball bearings and is driven by a handwheel for precise, comfortable operator adjustment.

Operation

• Self-centering pneumatic clamping — maximum clamping force up to 2 tons; opening/closing linked to carriage position; two sets of V-profile clamping jaws; maximum opening stroke 24 mm.
• Thread length adjustment via pneumatic stop inside the spindle.
• 5.6'' control screen to set spindle speed according to cutting parameters, diameter and thread pitch.
• Quick and easy mounting and setup of the chasers; chasers are resharpenable.
• Working position selectable on right or left side of the machine (to be defined on order).
• Automatic cooling/lubrication (watering).
• Motor: 7 kW, 6 poles.

Strengths

• Suitable for high-volume industrial production and long workpieces due to fixed-piece configuration and strong clamping.
• Operator-friendly design with simple manual adjustments and intuitive control interface.
• Cost efficiency through re-sharpenable cutting tools and low operating costs.
• Material and thread versatility: cylindrical or conical threads, right- or left-hand; compatible with ribbed bars, stainless steel, aluminium, bronze and plastics.

Technical specifications

• Model: F114.
• Engine power: 7.5 kW.
• Motor: 7 kW, 6 poles.
• Spindle torque: 2132 Nm.
• Clamping system: self-centering pneumatic clamp; max clamping force 2 tons; two sets of V-profile jaws.
• Clamping range: Ø33 – Ø114.
• Maximum clamp opening stroke: 24 mm.
• Thread length control: pneumatic stop internal to the spindle.
• Carriage: mobile on ball bearings, operated by handwheel.
• Head: threading head with automatic opening at end of cycle; opening/closing actuated by pneumatic cylinder linked to thread length.
• Control interface: 5.6'' screen for spindle speed, diameter and pitch settings.
• Chasers: resharpenable; easy mounting and adjustment.
• Cooling/lubrication: automatic watering.
• Applications: industrial intensive production, suitable for long pieces and a wide range of materials.
