Workpiece grinding machine FVGC-60

CNCprecisionstationary

-The FVGC Series of vertical grinding machine is easy setup, flexible and sealed to grinding. -The axial protection design creates a completely sealed machine during the grinding operation. -The worktable’s water-guided and waterproof design, which effectively prevents dust pollution, protects and increases the life span of precision transmission components. -The coolant and filtering system filters and separates cutting chips, powder and impurity from the coolant liquid during the machining processes. -The tool magazine’s automatic door provides fully enclosed dust-proof protection -The optional fourth axis can be installed as the second spindle for rotary machining of ring-shape workpieces, with a stable and low-speed feed. -Coolant-Through-Spindle System removes chips and heat from deep-hole machining and enhances tool cutting performance, longevity and parts accuracy. -The double-row cutting fluid spray pipe function can form a water curtain to lubricate and cool the cutting points of various parts during processing. -Spindle oil cooler can cool down the spindle temperature by constantly cycling the oil. -The centrifugal filtration device uses high-speed, rotating centrifugation to separate the cutting fluid from dust. -The water power filter or hydrocyclone system can filter and separate particles without the need to replace consumables. -The graphical conversational software for this machine is a perfect match for this industry’s small batch production needs in the punch industry. -An optional, table-mounted diamond roller dresser uses the graphic conversational function to grind different workpieces and perform grinding wheel dressing and compensation automatically
