AC/DC power supply PS1100A

adjustableswitchingwith short-circuit protection

PS1100A – 48V, 100W, DIN RAILThis 24V, 100W DIN rail power supply is a slim-design, DIN rail mounted Class I switching power supply, with a voltage output adjustable range of 48 - 56VDC, and an extended temperature range.Part Number: 32122-4 Voltage Output Adjustable 48 - 56VDC Universal AC input Short circuit, overload, over voltage protection Air convection cooling DIN rail installation Built in DC OK active signal NEC class 2/ LPS compliant Power on LED indicator No load power consumption < 1W 100% full burn-in tested The PS1100A product is a slim-design, 48V, DIN rail mounted Class I switching power supply featuring fully isolated plastic cases, extended operating temperatures from -10° to 60°C and 88% efficiency. Standard features include short circuit, overload, and over voltage protection, no load power consumption, and DC OK signal for monitoring status of the power supply unit. Includes: PS1100A UL Compliant fully isolated plastic Installation Method DIN rail (35MM) DIN Rail Spec TS35/7.5 or TS35/15 LED IndicatorsOutput voltage status Dimensions 3.9" x 2.2" x 3.5" 9.91 x 5.59 x 8.89 cm Product Weight 0.9 lbs 408.23 g
