CNC gear-hobbing machine DK 1000

Maximum nominal module - mm 14 Maximum dentable diameter - 1000 mm Useful tooth length - 700 mm Maximum length allowed between the tips - 1275 mm Table diameter / table passage hole - 780 mm / 180 mm Maximum allowed hob dimensions (ø x L) - 210 mm x 240 mm Tangential / shifting travel - 300 mm Plug connection for creator holder - ISO50 hydraulic Turns creator - 20 ÷ 450 rpm (600 with option) Turn the table - 0 ÷ 15 rpm Head tilt - ± 45 ° Machine weight without packaging - 13000 kg Installed power - Kw 72
