Linear actuator GB seriespneumaticpistoncompact
Add to favorites
Compare this product
Characteristics
- Movement
- linear
- Type
- pneumatic
- Technology
- piston
- Other characteristics
- compact, high-performance, standard
- Stroke
Max.: 10 in
Min.: 0.25 in
- Pressure
Max.: 100 psi
Min.: 20 psi
Description
Conoflow’s Pneumatic Piston Actuators are compact units designed to function in today’s high performance instrument systems. Piston diameters of 3” to 12.5” are available with standard strokes up to 10” (for stroke lengths greater than 10”, consult the factory). Integral positioners are standard for modulating service.
Force produced is a function of the supply pressure which can be varied from 20 to 100 PSI (138 to 690 kPa). Fast stroking speeds are made possible through the use of a high capacity positioner coupled with a unique cushion-loading regulator. The GB50 Series Piston Actuators are designed for use in corrosive atmospheres or adverse weather conditions.
