Electric drill UHD

Product overview

• Significant reduction of tool wear, extending tool life
• Lower cutting force for reduced operator effort and improved process efficiency
• Improved hole quality: minimized delamination, reduced fiber pull-out, better roundness and perpendicularity, lower hole-wall roughness
• Simplified drilling workflow for higher productivity and cost savings

Compatible tools and features

• Integrated drilling‑boring‑reaming step design to simplify operations and reduce costs
• Fine‑grain materials from international suppliers for high strength and wear resistance
• Left‑hand flute geometry enabling smooth, fast drilling and improved surface finish
• Step drill with four‑flute design for stable, precise drilling of CFRP and efficient machining of aluminum, titanium and laminated materials

Application cases
Suitable for hole-making in carbon-fiber composites, fiberglass, carbon-ceramic composites, superalloys, aluminium alloys, titanium alloys and other advanced materials.

Technical parameters
Item: UHD-PA
Power: 350 W
Model: UHD-PA40 | UHD-PA60 | UHD-PA185
Idle speed: 4,000 | 6,000 | 18,500 rpm
Damping device: Optional
Dust-collection device: Optional
Adaptive amplitude: None
Drilling diameter: ≤6 mm
Max. ultrasonic amplitude: 6 μm
Ultrasonic frequency: 15-30 kHz
Max. ultrasonic power: 70 W

Characteristics / technical specifications

• Item: UHD-PA
• Power: 350 W
• Model: UHD-PA40 | UHD-PA60 | UHD-PA185
• Idle speed: 4,000 | 6,000 | 18,500 rpm
• Damping device: Optional
• Dust-collection device: Optional
• Adaptive amplitude: None
• Drilling diameter: ≤6 mm
• Max. ultrasonic amplitude: 6 μm
• Ultrasonic frequency: 15-30 kHz
• Max. ultrasonic power: 70 W
