Air airborne particle counter OPC-6303FB

laserHVACfor pharmaceutical products

Cubic Explosion-Proof Particle Counter OPC-6303FB employs advanced light scattering technology, featuring an industrial-grade laser to deliver precise, real-time measurements of airborne particles. Designed for continuous monitoring of particle concentration in hazardous environments, OPC-6303FB provides stable 6-channel output for particle sizes (0.3μm, 0.5μm, 1.0μm, 2.5μm, 5.0μm, 10μm), with a sample flow rate up to 1 L/min. It supports both UART_TTL and I2C, enabling continuous monitoring of particle concentration. IP66 ex-proof enclosure ensures reliable performance across diverse hazardous environments, making it an ideal solution for industrial, chemical, battery production, etc. Features 1. 6 channels output for particle sizes of 0.3μm, 0.5μm, 1.0μm, 2.5μm, 5.0μm, and 10μm in pcs/L. 2. Light scattering technology with an industrial-grade laser for accurate particle identification. 3. Vehicle-grade fan with software algorithm control for stable and consistent sampling. 4. IP66 enclosure for hazardous environments. 5. Complies with explosive certifications, including Ex db eb IIC T6 Gb. Specifications Working Principle: Light scattering Measurement Range: 0~10,000,000pcs/L Output Channels: >0.3μm, >0.5μm, >1.0μm, >2.5μm, >5.0μm, >10μm Count Efficiency: 100pcs/L: ±30% of reading; Condition: 0°C-40°C, 50±10%RH Data Refresh Time: 1 second Working Conditions: -30°C~70°C, 0~95%RH (Non-condensing) Operating Voltage: DC 5V Average Operating Current: ＜250mA Communication: UART_TTL/IIC（3.3V/5V） Sampling flow rate: 1L/min IP Protection: IP66 Explosion-Proof Grade: Ex db eb lB T6 Gb; Ex db eb llC T6 Gb; Ex tb lllC T80°C Db Dimensions: W200*H200*D90 (mm)
