Height Adjustment:
One-touch Spline Controller
Adjustment Increments:
Minimum 0.1 mm step
Usages:
Plate & Pipe's beveling for weld preparation
Maximum Bevel range per angle:
0° ~ 90°
Deg. / Thickness (inch) / Width (inch)
30° / 8.3mm (0.326) / 9.6 (0.378)
45° / 6mm (0.236) / 8.5 (0.334)
Pipe size:
15A[21.7mm or 1/2" ]~ 250A[267.3mm or 10
Weight:
3.2kg
Power:
850W
Inserts Tip:
3EA / CFWB080360
Applications:
Steel (carbon & stainless steel, etc.), Non-ferrous metal, other materials
