Vehicle detection gate CS0200T
Add to favorites
Compare this product
Characteristics
- Applications
- for vehicles
Description
CS0200T X-Ray Scanner – Top-View Light Vehicle Inspection – 2 Operating Modes – Patented Conveyor – Material Discrimination
Mobile inspection system for light vehicles with rapid deployment generating top-view scan images. The CS0200T adopts a patented conveyor transporting vehicles through the tunnel and provides high-quality images. Particularly suited for chassis inspection. Flexible deployment at land borders, police checkpoints, and major event entrances. Modular lightweight design requiring no civil engineering works. Reduced footprint and high installation flexibility.
High-Quality Top-View Imaging
High-quality top-view scan images enabling identification of contraband or dangerous materials concealed.
Particularly suited for detailed chassis inspection.
Generates distortion-free horizontal vehicle image thanks to overhead-mounted generator.
225 keV X-ray tube with ≥40 mm steel penetration at 8 km/h (drive-through mode) or ≥50 mm steel (conveyor mode).
Dual-Energy Material Discrimination
Dual-energy X-ray imaging technology discriminating organic, inorganic, and mixed materials. Materials marked by specific color codes facilitating identification of contraband and dangerous goods concealed in vehicle.
Patented Conveyor and Self-Shielding
Patented two-piece conveyor with no imaging blockage impact on vehicle.
Optional self-shielding structures effectively reducing radiation protection zone.
Safety equipment: CCTV, PA system, safety interlocks. Radiation protection compliant with IAEA, ICRP, and WHO standards.
Technical Specifications
Mobile inspection system for light vehicles with rapid deployment generating top-view scan images. The CS0200T adopts a patented conveyor transporting vehicles through the tunnel and provides high-quality images. Particularly suited for chassis inspection. Flexible deployment at land borders, police checkpoints, and major event entrances. Modular lightweight design requiring no civil engineering works. Reduced footprint and high installation flexibility.
High-Quality Top-View Imaging
High-quality top-view scan images enabling identification of contraband or dangerous materials concealed.
Particularly suited for detailed chassis inspection.
Generates distortion-free horizontal vehicle image thanks to overhead-mounted generator.
225 keV X-ray tube with ≥40 mm steel penetration at 8 km/h (drive-through mode) or ≥50 mm steel (conveyor mode).
Dual-Energy Material Discrimination
Dual-energy X-ray imaging technology discriminating organic, inorganic, and mixed materials. Materials marked by specific color codes facilitating identification of contraband and dangerous goods concealed in vehicle.
Patented Conveyor and Self-Shielding
Patented two-piece conveyor with no imaging blockage impact on vehicle.
Optional self-shielding structures effectively reducing radiation protection zone.
Safety equipment: CCTV, PA system, safety interlocks. Radiation protection compliant with IAEA, ICRP, and WHO standards.
Technical Specifications
- X-ray source: X-ray tube
- X-ray energy: 225 keV
- Maximum vehicle dimensions: 5.6 m (L) × 2.1 m (W) × 2.1 m (H)
- Penetration: ≥40 mm steel at 8 km/h (drive-through) / ≥50 mm steel (conveyor)
- Throughput: 150 vehicles/hour (drive-through) / 40-45 vehicles/hour (conveyor)
- Scan speed: 5-15 km/h, typical 8 km/h (drive-through) / 0.2-0.4 m/s (conveyor)
- Operators: 1 (system control & image analyst)
- System dimensions: 2.8 × 4.5 × 3.5 m (drive-through) / 16.5 × 4.5 × 3.5 m (conveyor)
- Available modes: Drive-through (driver passes directly) / Conveyor (conveyor transfers vehicle)
