Water cleaning station BRSO 8000 SM2E2A

for industrial applications

Summary
Detachable vehicle wash area composed of a custom-made flexible retention basin in a mixed version (2 sides with aluminium angle supports to insert into sleeves and 2 self-supporting sides with foam tubes and integrated reinforcement plates). Foldable, easy to transport and quick to install; suitable for containment of wash water, hydrocarbons and pollutant products. For occasional or permanent use.

Product reference
BRSO 8000 SM2E2A

Detailed description
Composition and operating principle:

• Mixed flexible retention basin allowing passage of machinery without assembly/disassembly on the self-supporting sides.
• 2 self-supporting sides fitted with foam tubes (Ø 75 mm) and integrated reinforcement plates.
• 2 sides equipped with aluminium angle supports to insert into sleeves, spaced at 40 cm.
• Material: polyester fabric coated with PVC (900 g/m2).

Uses

• Cleaning and washing of construction and industrial vehicles.
• Temporary or permanent containment of wash water, hydrocarbons and other pollutants draining from trucks and equipment.
• Can also be used as a storage area with retention or as a decontamination/filling zone.

Benefits

• Foldable design with low storage footprint and transportable handling.
• Simple and quick installation; easy assembly/disassembly.
• Reusable design suitable for repeated deployments.
• Compatible with small equipment as well as large machines.

Available options

• Rubber reinforcement strips for wheel passages.
• Drain valve.
• Specific lining for corrosive products.

Manufacturing
Manufactured in France.

Specifications / technical data

• Reference: BRSO 8000 SM2E2A
• Type: foldable flexible wash area (mixed flexible retention basin)
• Material: polyester coated with PVC 900 g/m2
• Dimensions: 8 x 4 m
• Height: 0.25 m
• Retention capacity: 8000 litres
• 2 self-supporting sides: foam tubes Ø 75 mm + integrated reinforcement plates
• 2 sides with aluminium supports to insert into sleeves (spacing 40 cm)
• Installation: no assembly required for vehicle passage on self-supporting sides
• Use: occasional or permanent; compatible with containment of wash water, hydrocarbons and pollutants
