hydraulic auger / for excavators
150 - 1 000 lpm | MD series
hydraulic, for excavators
The Digga Mega drilling drive and Screw Anchor Drive range is not for the faint hearted and is the ultimate in Mega high torque performance up to 200,000Nm. Fitted with the world first I-Drive hydraulic motor system these units are able to utilize the total available horsepower of your Excavator to deliver maximum power to the application. Designed for maximum efficiency, easy fitment and reduction of operator error (i.e. no need for case drain) these units are bullet proof.
Fully Australian Designed and Manufactured, the WORLD FIRST Digga 'I-Drives' are high capacity, compact, hydraulic drive systems fitted to Digga Hi Torque Planetary Gearboxes. Designed to fit 12 - 50 Tonne excavators for the installation of ground screw anchors, core barrelling and foundation drilling.
The cost effective I-Drive systems can fully utilize the total available horse power of the machine, accepting flows 375, 500, 750 & 1000 lpm with single/dual or three speed options (high speed/low torque, mid speed/mid torque, low speed/high torque)
No Case Drain Required
No Complex hose, valving or filtration
No Detuning of machine required
In built Pressure Relief Valve as standard
1-2 and 3 speeds available up to 1,000 lpm.
