Programmable signal conditioner PI3EQX12902E

8 Gbps 3.3V, PCIE3/SATA3 1 port/2 channel Low Power Linear Redriver, Interleave, Modern Standby Mode PI3EQX12902E is a low power, high performance 8 Gbps 2 channels PCIe® 3.0/SATA3 linear ReDriver™. The device provides programmable equalization, linear swing and flat gain to optimize performance over a variety of physical mediums by reducing Inter-Symbol Interference. PI3EQX12902E supports two 100 Ω Differential CML data I/O’s between the Protocol ASIC to a switch fabric, over cable, or to extend the signals across other distant data pathways on the user’s platform. The integrated equalization circuitry enhances the signal integrity of the waveform through the ReDriver. Each channel operates independently. The channels’ input signal level determines whether the output is active. The PI3EQX12902E is a flexible, multi-protocol linear ReDriver designed to support new chipsets with dual protocol I/O pins, which support 8 Gbps PCIe 3.0 and 6 Gbps SATA3 speeds. It also supports connectors such as mSATA/M.2/SATAe/U.2 that provide control signals. The PI3EQX12902E is also an excellent choice for single lane applications requiring low power and small package for docking station connectivity. Notebook PC Server Motherboards Rack Server JBOD Storage Blade Server 8 Gbps Serial Link with Linear Equalizer Two 8 Gbps Differential Signal Pairs Supports PCIe 3.0/SATA3 Protocols Supports Modern Standby Requirement Transparent to link training, OOB, Idle Pin Adjustable Receiver Equalization Pin Adjustable output linear swing Pin Adjustable Flat Gain 100 Ω Differential CML I/O’s Auto receiver detection for adaptive power management Auto “low power” mode for adaptive power management
