Hand-held fume extractor FRED JR
weldingcartridgeautomatic

hand-held fume extractor
hand-held fume extractor
hand-held fume extractor
Add to favorites
Compare this product


Characteristics

Mobility
hand-held
Applications
welding
Filter type
cartridge
Other characteristics
automatic, compact, with extraction arm
Airflow

Max.: 1,800 ft³/min (51 m³/min)

Min.: 1,200 ft³/min (34 m³/min)

Description

Keeping your worker’s breathing zone safe requires a capture-at-source extractor they will actually use. Designed to be moved and positioned effortlessly, the FRED-JR excels at removing weld fumes, dusts, and other airborne contaminants as small as 0.5 micron with a standard nanofiber filter. Maintenance of the Fred Jr's filter cartridge is clean and easy since operators are not exposed to airborne dust from blowing the filers clean. The unit is designed to collect particles on the inside of the cartridge, allowing operators to clean the filters with compressed air without creating a dust cloud in your facility. The capture arm's external articulation protects the arm's components from wear and tear, as smoke and dust passes through the arm without contacting the swivel and pivot points of the supporting structure. The high suction and capture velocity developed by the Fred JR alows operators to capture and filter dust and fumes further away from the hood than competitive models. Benefits Compact, portable, and easy to operate Capture-at-source for cleaner air Complies with OSHA guidelines for controlling weld fumes Features Flexible 10' Externally Articulated Capture Arm 1.5HP TEFC Motor producing 1200 CFM of airflow 26" Easy-to-Service Cartridge Filter Rotary Starter with 15' Power Cord included

VIDEO
