Cylindrical grinding machine IGV-1NT

workpieceCNCprecision

Operability improved by its vertical structure Easy workpiece setup and centering with both hands Stable workpiece seating on a chuck with less clamping force Roundness of less than 1µm achieved with Taiyo Koki's standard test piece Multi-process grinding enabled by turret-type wheel head Both internal and external grinding spindles equipped as standard, which enables grinding of ID, OD and face in one-time chucking Internal grinding spindle : selectable from 30,000min-1, 45,000min-1 or 75,000min-1 External grinding spindle : 3,700min-1 High productivity in a compact installation space Minimized installation space with machine width 1,190mm x depth 3,100mm Suitable for high-accuracy, high-efficiency grinding of mass-produced precision parts Other features Automation systems available such as robot, loader, stocker, etc. (option) Chucking systems available such as precision air chuck, diaphragm chuck, collet chuck, etc. (option) Automatic measurement system (option) Scale feedback control for X/Z-axis (option) Single point dresser (Rotary dresser and AE dresser available as an option)
