Scroll vacuum pump HF-E0-100
lubricated48VDCsingle-stage

Scroll vacuum pump - HF-E0-100 - Dongguan Yazreid Electromechanical Technology Ltd - lubricated / 48VDC / single-stage
Scroll vacuum pump - HF-E0-100 - Dongguan Yazreid Electromechanical Technology Ltd - lubricated / 48VDC / single-stage
Scroll vacuum pump - HF-E0-100 - Dongguan Yazreid Electromechanical Technology Ltd - lubricated / 48VDC / single-stage - image - 2
Add to favorites
Compare this product

Characteristics

Technology
scroll
Lubrication
lubricated
Supply voltage
48VDC
Number of stages
single-stage
Applications
plasma, cleaner, tank
Other characteristics
small, portable
Ultimate vacuum

1 mbar
(0.01 psi)

Flow rate

100 l/min
(26.42 us gal/min)

Power

200 W, 350 W
(0.27 hp, 0.48 hp)

Operating temperature

Min.: -40 °C
(-40 °F)

Max.: 50 °C
(122 °F)

Length

324 mm, 394 mm
(13 in, 16 in)

Width

225 mm, 236 mm
(8.86 in, 9.29 in)

Height

175 mm, 189 mm
(6.89 in, 7.44 in)

Noise level

56 dB, 60 dB

Weight

6.7 kg, 7.8 kg
(14.77 lb, 17.2 lb)

Description

1. The world's first Maglev scroll vacuum pump 2.100% oil-free; maintenance-free; clean vacuum environment 3. The maximum pumping speed of the vacuum pump is 100 L/min 4. The maximum ultimate vacuum is less than 1.5 Pa 5. Small size, light weight,ideal vacuum equipment for portable equipment 6. Application areas: scientific analytical instruments (mass spectrometers, tank clearers), laboratories equipment (laboratory freeze dryer), foreline pump of the molecular pump, plasma cleaner, etc. As a recognized and wellknown manufacturer of vacuum pumps, Hokaido Vacuum Technology(Int'l) Group has been leading the development of vacuum technology for the industrial applications since the year of establishment. With the continuously developing and daily internationalizing, Hokaido has built 3 highly modernized manufacturing centers with first-class processing equipments installed throughout china, which are Dongguan Yazreid M&E Technology Co Ltd, Haokede Vacuum Technology(Shanghai) Co Ltd, Hokaido Vacuum Technology(Shandong) Co Ltd.
