Diesel forklift D series
ride-onhandlinglow-noise

Diesel forklift - D series - Doosan Industrial Vehicles - ride-on / handling / low-noise
Diesel forklift - D series - Doosan Industrial Vehicles - ride-on / handling / low-noise
Diesel forklift - D series - Doosan Industrial Vehicles - ride-on / handling / low-noise - image - 2
Diesel forklift - D series - Doosan Industrial Vehicles - ride-on / handling / low-noise - image - 3
Diesel forklift - D series - Doosan Industrial Vehicles - ride-on / handling / low-noise - image - 4
Diesel forklift - D series - Doosan Industrial Vehicles - ride-on / handling / low-noise - image - 5
Diesel forklift - D series - Doosan Industrial Vehicles - ride-on / handling / low-noise - image - 6
Diesel forklift - D series - Doosan Industrial Vehicles - ride-on / handling / low-noise - image - 7
Diesel forklift - D series - Doosan Industrial Vehicles - ride-on / handling / low-noise - image - 8
Diesel forklift - D series - Doosan Industrial Vehicles - ride-on / handling / low-noise - image - 9
Diesel forklift - D series - Doosan Industrial Vehicles - ride-on / handling / low-noise - image - 10
Add to favorites
Compare this product

Characteristics

Motor type
diesel
Operator
ride-on
Applications
handling
Other characteristics
low-noise
Carrying capacity

6 t, 7 t, 8 t, 9 t
(6.6 us ton, 7.7 us ton, 8.8 us ton, 9.9 us ton)

Lifting height

Min.: 2,800 mm
(110.24 in)

Max.: 7,275 mm
(286.42 in)

Overall width

2,156 mm, 2,230 mm
(84.9 in, 87.8 in)

Overall length

4,818 mm, 5,214 mm, 5,240 mm
(189.7 in, 205.3 in, 206.3 in)

Load center distance

600 mm
(23.6 in)

Weight without load

9,435 kg, 11,330 kg, 11,980 kg
(20,800.6 lb, 24,978.4 lb, 26,411.4 lb)

Axle loading with maximum load front

13,530 kg, 17,165 kg, 18,625 kg
(29,828.5 lb, 37,842.3 lb, 41,061.1 lb)

Axle loading with maximum load rear

1,970 kg, 2,230 kg, 2,420 kg
(4,343.1 lb, 4,916.3 lb, 5,335.2 lb)

Axle loading without load front

4,285 kg, 4,820 kg, 4,900 kg
(9,446.8 lb, 10,626.3 lb, 10,802.7 lb)

Axle loading without load rear

5,150 kg, 6,430 kg, 7,160 kg
(11,353.8 lb, 14,175.7 lb, 15,785.1 lb)

Track width front

1,584 mm, 1,668 mm
(62.4 in, 65.7 in)

Track width rear

1,550 mm, 1,750 mm
(61 in, 68.9 in)

Height of mast when lowered

2,495 mm, 2,835 mm
(98.2 in, 111.6 in)

Free lift

205 mm, 215 mm
(8.1 in, 8.5 in)

Overall height with mast raised

4,275 mm, 4,375 mm
(168.3 in, 172.2 in)

Height to top of overhead guard

2,468 mm, 2,673 mm
(97.2 in, 105.2 in)

Seat height

1,455 mm, 1,526 mm
(57.3 in, 60.1 in)

Length to fork face

3,618 mm, 4,014 mm, 4,040 mm
(142.4 in, 158 in, 159.1 in)

Fork carriage width

2,156 mm, 2,216 mm
(84.9 in, 87.2 in)

Ground clearance under mast with load

196 mm, 283 mm
(7.7 in, 11.1 in)

Ground clearance at center of wheelbase with load

214 mm, 329 mm
(8.4 in, 13 in)

Turning circle radius

1,344 mm, 1,468 mm, 3,380 mm, 3,650 mm, 3,680 mm
(52.9 in, 57.8 in, 133.1 in, 143.7 in, 144.9 in)

Travel speed

30 km/h, 30.7 km/h
(18.6 mph, 19.1 mph)

Lifting speed

430 mm/s, 470 mm/s, 480 mm/s, 530 mm/s

Lowering speed

0.45 m/s, 0.5 m/s
(1.476 ft/s, 1.64 ft/s)

Rated drawbar pull

Min.: 5,009 N

Max.: 7,360 N

Gradeability

Min.: 34.8 %

Max.: 75 %

Rated output

55.4 kW, 80.9 kW
(75.3 hp, 110 hp)

Rated speed

2,300 rad.min-1
(366.1 rpm)

Cubic capacity

3,409 l
(900.6 gal)

Maximum operating pressure

140 bar
(2,030.5 psi)

Oil flow

120 l/min, 135 l/min
(31.7 us gal/min, 35.7 us gal/min)

Noise level

72 dB, 74 dB

Description

The Bobcat 6.0–9.0t diesel forklifts offer remarkable fuel efficiency and remarkable performance. The premium 9-Series forklifts flawlessly combine the user-friendly nature of operating a Bobcat forklift with first-rate safety features, superior ergonomics ensuring unmatched operator comfort, and adjustable controls aimed at maximizing productivity. Heavyweight Efficiency 55 or 81 kW DM03V engines with a Bosch common rail system deliver low fuel use and top travel, lift and gradeability. 1,000-hour intervals and auto-tension systems cut downtime and cost. Confidence: Built In Rear camera, anti-surge and EPB add safety. Enjoy a spacious, low-noise cab with HVAC and a 7" display for clear views and convenience during long shifts. Strength & Easy Service Watch 9-Series forklifts move big loads with quiet power and quick service access, including a 60° tilting compartment. Ergonomics Significantly Lower Noise Level 2 large air filters clean the supplied air. Very low noise and vibration level inside the cabin for high driving comfort. Centralized Switches All switches are positioned for optimal operator convenience. Ergonomic parking lever position on the left side of the seat. The neat and wide-open floorboard provides the operator with plenty of leg space to make entry and exit a breeze. Integrated Type 7” Multi-Function Display Panel The largest mounted display in its class provides excellent operability and visibility. Front and rear view cameras PIN code Integrated maintenance management program Weight indicator Diagnostic function Located on the A-pillar for optimal view
