Electronic autocollimator E

• An upgraded device based on our already mature technology for testing and adjusting fully integrated systems including mechanics, optics, and lasers. • Emerging optomechatronics AR/VR industry has introduced special applications requirement: ○ Interalignment and testing of lasers, optics, mechanics and electronic sensors ○ Angular accurate optical measurements with resolution of 0.01 arc sec or better. ○ Implementing fusion of several wavelengths including NIR into one system. ○ Measurements from remote mechanical dimensions. ○ Centering & Alignment ○ Measurements of multi laser array such as VCSEL in respect with other optical sensors. • Our Total Station Autocollimator does it all and much more, including projection of virtual objects from user defined distance. The application program is compatible with Windows 8/10/11 OS (32 & 64 bit). For custom integration, an SDK package software is offered as standard. General Measurements Straightness measurement – up to 2.5 meters Remote Lateral Mechanical Measurements – microns accuracy Testing of optical elements, including roll angle Image Projection & Focusing Target projection for optical systems from 2.5 meters to infinity Motorized Focusing from 0.18 meters to infinity
