Heavy-duty pipe clamp 11 001 series

For pipes up to 80 inch 90% of the root can be welded Pipe range OD: 12 - 80 inch Available in a medium, heavy and Edge misalignment can be eliminated by means of jackscrews The air gap can be adjusted by means of chisel Our Hydraulic External Pipe Clamps have a wide gap, which allows the welding of the root up to 90% before removing the clamp. Edge misalignment can be eliminated by means of jackscrews or a wedge which is placed under the alignment bridge. The air gap can be adjusted by means of chisel. The hydraulic cylinder, which is available as an option, operates in all positions and can be used for all pipe diameters. MEDIUM HYDRAULIC EXTERNAL PIPE CLAMP The medium external pipe clamps have a wide gap, allowing welding of the root up to 90% before removing the clamp. Edge misalignment can be eliminated by means of jackscrews or a wedge which is placed under the alignment bridge. HEAVY DUTY HYDRAULIC EXTERNAL PIPE CLAMP Heavy Hydraulic External Pipe Clamp. The hydraulic cylinder works in vertical position and can be exchanged easily, if necessary. The alignment bridges have a widegap, allowing to weld the root up to 90% before removing the clamp. Hydraulic jack 10 t. For gas pipelines (fine-grained steel) and for thick-walled pipes made of study flat steel.
