Module mass (front/rear) - 3850 kg/ 3550 kg
Traction
Speed range - 0-12 km/h
Vertical oscillation - ±7
Max. theoretical gradeability - 49 %
Compaction
Wheel load - 888 kg/wheel
Centrifugal force (high/low amplitude) - 78/ 67 kN
Nominal amplitude (high/low) - 0.70/ 0.30 mm
Static linear load - 25.7 kg/cm
Vibration frequency (high/low amplitude) - 48/ 67 Hz
Water tank - 750 l
Emulsion tank - 78 l
Engine
Manufacturer/Model - Deutz TCD 3.6 HT T4f
Type - Water cooled turbo Diesel
Fuel tank capacity - 130 l
Alternative Engine
Manufacturer/Model - Cummins QSB 3.3 IIIA/T3
Type - Water cooled turbo Diesel
Fuel tank capacity - 130 l
Alternative Engine
Manufacturer/Model - Deutz TCD 3.6 HT StageV
Type - Water cooled turbo Diesel
Hydraulic system
Driving - Axial piston pump with variable displacement. Axial piston motors (3) with variable displacement.
Vibration - Axial piston pump with variable displacement.
Axial piston motor with constant displacement.
Steering - Gear pump with constant displacem.
Service brake - Hydrostatic in forward and reverse lever.
Parking/
Emergency brake - Failsafe multidisc brake in both drums.
