triaxial accelerometer / piezoelectric / IEPE / with built-in electronics
3062B1

{{requestButtons}}

Characteristics

  • Number of axes:

    triaxial

  • Technology:

    piezoelectric, IEPE

  • Other characteristics:

    with built-in electronics, hermetic

  • Acceleration range:

    1,961 m/s² (6,434 ft/s²)

  • Frequency:

    Max.: 10,000 Hz

    Min.: 0.48 Hz

Description

The Model 3062B1 by Dytran is specifically designed to provide an extremely high quality performance and functionality for very specific purposes. It is an IEPE piezoelectric accelerometer ideally constructed to be used on wide band frequency vibration measurement points of the Rotor, Track and Balance. It is considered as the "spark plug type" of tool by several related industries due to their same appearance. It is integrated with a 25 mV/g sensitivity capacity which features a stainless steel device used for several applications involving high humidity.
