Cable ladder fishplate ULIH series

stainless steelcorrosion-resistant

Description
Horizontal splice plate for UL cable ladder systems. Screwless connection, standard length 150 mm, manufactured in stainless steel (EN 1.4404 / AISI 316L). Designed to join ladder sections securely while ensuring corrosion resistance for industrial installations.

Material and color
Material: Stainless steel (EN 1.4404 / AISI 316L)
Color: None (natural stainless finish)

Dimensions available (summary)
Product — EAN — (Cable ladder) Height (mm) — Length (mm)
ULIH 53 E4 — 4013339960194 — 53 — 150
ULIH 80 E4 — 4013339960200 — 80 — 150
ULIH 100 E4 — 4013339960217 — 100 — 150
ULIH 150 E4 — 4013339960224 — 150 — 150

Characteristics / technical specifications

• Type: Splice plate (horizontal)
• Fastening: Screwless
• Standard length: 150 mm
• Material: Stainless steel
• Material code: EN 1.4404 (AISI 316L)
• Color: None
• Compatibility: For UL cable ladder system, multiple tray widths available
• Available variants and EAN: ULIH 53 E4 (Height 53 mm, EAN 4013339960194), ULIH 80 E4 (Height 80 mm, EAN 4013339960200), ULIH 100 E4 (Height 100 mm, EAN 4013339960217), ULIH 150 E4 (Height 150 mm, EAN 4013339960224)
• Documentation: Product datasheets available for each variant
