Centrifugal fan S series
explosion-proofATEXAC

Centrifugal fan - S series - Electronics Associates - explosion-proof / ATEX / AC
Centrifugal fan - S series - Electronics Associates - explosion-proof / ATEX / AC
Add to favorites
Compare this product
Go to the Electronics Associates website for more information

Characteristics

Configuration
centrifugal
Function
explosion-proof, ATEX
Supply voltage
AC
Air flow

Max.: 373.2 m³/h
(13,179.434 ft³/h)

Min.: 42 m³/h
(1,483.216 ft³/h)

Diameter

Max.: 172 mm
(6.772 in)

Min.: 80 mm
(3.15 in)

Description

Certification
ATEX certificate issued according to: 2014/34/EU Directive - Annex III Module B.

Classification
Ex II 3G Ex ec IIc T4 Gc.

Models and performance
  • S172SAP (Ex67) — 172 x 150 x 51 mm / 6 x 2 inch — 6.22 m3/min / 220 CFM — Thermal protection
  • S109PT (Ex67) — 119 x 119 x 38 mm / 4.7 x 1.5 inch — 3.82 m3/min / 135 CFM — Impedance protection
  • S125PT (Ex67) — 120 x 120 x 25.5 mm / 4.7 x 1 inch — 2.12 m3/min / 75 CFM — Impedance protection
  • S938PT (Ex67) — 92 x 92 x 38.5 mm / 3.6 x 1.5 inch — 1.47 m3/min / 52 CFM — Impedance protection
  • S92PT (Ex67) — 92 x 92 x 26 mm / 3.6 x 1 inch — 0.99 m3/min / 35 CFM — Impedance protection
  • S838PT (Ex67) — 80 x 80 x 38.5 mm / 3 x 1.5 inch — 0.84 m3/min / 30 CFM — Impedance protection
  • S825PT (Ex67) — 80 x 80 x 26 mm / 3 x 1 inch — 0.70 m3/min / 25 CFM — Impedance protection

Notes
  • We reserve the right to change the data without further notice.
  • Data performance subject to ±10% tolerance.

Technical specifications
  • ATEX certificate: issued according to 2014/34/EU Directive - Annex III Module B
  • Classification: Ex II 3G Ex ec IIc T4 Gc
  • Available models and key data as listed above (size, max airflow, protection type)
