Automatic retractable bollard JS80

hydraulichigh-securitysteel

Overview
The FAAC JS80 bollards are crash-rated perimeter protection units certified to stop a 7,500 kg truck at 80 km/h with certified operation after impact. The JS80 is designed for fixed perimeter security in commercial and critical infrastructure sites. Protective mDure® covers allow reconditioning of the bollard without full disassembly, reducing lifecycle maintenance costs. Rilsan® anticorrosive polyamide resin provides long-lasting protection against corrosion, weather and chemical agents.

Key features

• Crash rating: certified to stop a 7,500 kg truck at 80 km/h (PAS 68, IWA 14-1, ASTM F2656)
• mDure® protective sleeve with optional Aisi 316L stainless steel sleeve
• Rilsan® anticorrosive coating for enhanced durability
• Reduced maintenance and simplified reconditioning
• Suitable for commercial, industrial and certified perimeter security installations

Technical specification

• Diameter: 275 mm
• Rising height: 1,000 mm
• Body material: High performance steel
• Protective sleeve: mDure®; optional Aisi 316L protective sleeve
• Operating temperature: -15°C to +80°C (standard); -40°C to +80°C (with heater)
• Standards: PAS 68, IWA 14-1, ASTM F2656

Model variants

• JS 80 HA — Part No. 117501 — Commercial; Certified perimeter security — Cylinder height 1000 mm — Approx. rising time 1.50 s — Approx. descent time 2.00 s
• JS 80 HA EFO — Part No. 117551 — Commercial; Certified perimeter security — Cylinder height 1000 mm — Approx. rising time 1.50 s — Approx. descent time 2.00 s
• JS 80 R — Part No. 117601 — Commercial; Certified perimeter security — Cylinder height 1000 mm — Rising/Descent time N/A
• JS 80 F — Part No. 117651 — Commercial; Certified perimeter security — Cylinder height 1000 mm — Rising/Descent time N/A
• JS 80 HA Stainless Steel — Part No. 117701 — Commercial; Certified perimeter security — Cylinder height 1000 mm — Approx. rising time 1.50 s — Approx. descent time 2.00 s
• JS 80 HA EFO Stainless Steel — Part No. 117751 — Commercial; Certified perimeter security — Cylinder height 1000 mm — Approx. rising time 1.50 s — Approx. descent time 2.00 s
• JS 80 R Stainless Steel — Part No. 117801 — Commercial; Certified perimeter security — Cylinder height 1000 mm — Rising/Descent time N/A
• JS 80 F Stainless Steel — Part No. 117851 — Commercial; Certified perimeter security — Cylinder height 1000 mm — Rising/Descent time N/A
