Thermal transfer label printer B-FV4T

direct thermalmatrixdesktop

Handy and lightweight desktop printer for direct thermal and thermal transfer printing. Print width up to 108 mm TOSHIBA BFV4T PRINTER Toshiba B-FV4T Direct Thermal/Thermal Transfer Printer (203 dpi - 300 dpi) B-FV4T series printers are characterized by high reliability and a structure suitable to be inserted in small spaces. Suitable for low/medium volume printing, they are ideal for ticketing and public applications (sanitary, stadiums, restaurants, amusement parks, offices) For label printing you can use the program provided for free in the installation CD. The use is very intuitive. Model: B-FV4T Technology: Thermal transfer / direct thermal Head type: Flat Print width: From 22.4 to 108 mm Print length: From 8 to 999 mm Material width: 25.4 - 118 mm Print speed: Up to 152.4 mm/sec (6 ips) Resolution: 203 / 300 DPI Memory capacity: 16 MB DRAM, 32 MB Flash ROM Interfaces: USB 2.0, LAN 10/100 BaseT, RS-232C 2D codes: Data Matrix, PDF 417, Maxicode, Micro PDF 417, QR code Barcode: Code 39, Code 39C, Code 93, Code 128 UCC, Code 128, Code 11, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5), MSI, ITF, Plessey, Postnet, RSS Dimensions: 220 x 182 x 279 mm Weight: 2.4 kg (without support and adapter AC) OPTIONAL available: - Cutter for complete cutting - Cutter for partial cutting - Label peeler module - External roll holder - Bluetooth *it is not possible to mount a partial cut cutter together with a full cut cutter INKING TAPE USABLE WITH TOSHIBA B-FV4T Outer tape diameter: 65 mm Inner belt core diameter: 25.4 and 12.7 mm Tape length: 300 m maximum The inked tape is divided into three types depending on the percentage of wax or resin present and is chosen depending on the use to be made. LABELS WHICH MAY BE USED: Core diameter (internal): 25.4/ 38.1 - (optional: 76.2 mm with external roll holder) External roll diameter: 127 mm - (optional: 203 mm with external roll holder) Material thickness: 0.06 - 0.19 mm WAX TYPE (WAX) - AW6F and AW1F It works at not very high temperatures, extending the life of the printer. Being a mormide component, the useful life of the label is less than labels printed with wax-resin or resin. Suitable for paper supports. WAX-RESIN TYPE (Wax/Resin) SG3F Composed of high percentages of wax and resins and with polyester base. Excellent quality/ price ratio TYPE RESIN (Resin) AS1F Composed of high percentages of resins and with polyester base. High resistance to abrasive agents and print quality on surfaces such as paper, plastic and translucent paper. Better quality SIMPLE INSTALLATION: The printer comes already complete with drivers and free basic software for creating labels and printing logos and barcodes. The printer is free installation.
