Bar cut-to-length cutting line for steelfor stainless steelstacking
Add to favorites
Compare this product
Characteristics
- Material
- for steel, for stainless steel
- Product handled
- bar
- Associated function
- stacking, straightening, deburring
- Applications
- for industrial applications
- Other characteristics
- hydraulic, custom-made, transversal
Description
TX’s cut to length lines for cutting flat bar are designed for producing the superior quality flat bar. For the reasons of safety and appearance reasons, the edging processing is involved to remove the burr that is produced during slitting.
TX’s flat bar deburring and transversal cutting line features:
• Materials: all kinds of steel including stainless steel.
• Thickness: 10mm max.
• Deburred edges on the flat bars.
• Free of camber.
• Very good flatness and straightness is obtained.
• Stacking system for different cut length.
• Different level of automation.
• Customization is available.
Below is the common configuration of TX’s flat bar cut to length line:
• Uncoiler
• Coil Car
• Peeler
• Pinch roll
• Flattening unit
• Deburring unit + straightening unit
• Flattening unit
• Hydraulic shear(cut-to-length)
• Stacker
