Earth-fault detector X72DB3

Overview
The X...DB3 series Type B earth leakage relay X72DB3 provides automatic detection of continuous (DC), alternating (AC) and high-frequency leakage currents. It offers continuous, immediate insulation-status monitoring via a multi-coloured display and is intended for 72 x 72 mm panel-mount installation. Suitable for industrial distribution boards and control cabinets with electronic loads, converters, PV inverters and charging stations where complex leakage currents may occur.

Note
This model has been superseded by the newer X72DB4 (replacement indicated on the product sheet).

Panel dimensions / cut-out
Panel cut-out / front size: 72 x 72 mm

Documentation and downloads available

• Datasheet (PDF)
• User manual (PDF)
• Available options list (PDF)
• Certifications (PDF)
• Technical drawing (PDF)

Technical drawings

• DWG technical drawing (available)
• PDF technical drawing

Multimedia

• Product and corporate videos demonstrating Type B earth leakage relays and installation

Notes

• Product presented in 72 x 72 mm panel format
• Series designation: X...DB3 (Type B earth leakage relays)

Technical specifications

• Series: X...DB3
• Model: X72DB3
• Type: Type B earth leakage relay
• Panel cut-out / front size: 72 x 72 mm
• Leakage detection: continuous (DC), alternating (AC) and high-frequency leakage currents
• Insulation monitoring: continuous, immediate indication via multi-coloured display
• Intended use: monitoring and protection of installations with electronic loads and converters
• Available resources: datasheet, user manual, options list, certifications, technical drawings and videos
