Servo-driven packing machine AF-25K/50K II

verticalgranularbag

GM PaxGo Duplex Packing Scale with 3 Load Cells Structure 25KG/50KG GM PaxGo Duplex Packing Scale AF-25K II and AF-50K II have a 3 - load cell structure and servo motor control. They are designed for fast and accurate granular material weighing and packing. The vibrator feeder can be added to the structure for material flow consistency and high accuracy. Great Performance AF-25K II 's weighing range: 5~25kg, best accuracy: ±15g, highest speed: 2200pcs/h AF-50K II 's weighing range: 10kg~50kg, best accuracy: ±25g, highest speed: 2000pcs/h Jumbo bag's weighing range: 500kg~50t, best accuracy: ±500g, speed: 1t/min Industrial Design Module design with standard flange interface Stepping Motor for feeding control with intelligent auto adjustment Embedded USB for exporting data and system upgrading Superior packaging controller SS304 stainless steel for food contacting materials of the machine User-friendly Design 10-inch touch screen Easy and fast installation Well-organized data management Motor parameters: an interface can simultaneously display the motor status and parameters All definitions of each port can be intuitively selected
