Cable stripping machine GM ROTAX 30

cable stripping machine
cable stripping machine
cable stripping machine
Add to favorites
Compare this product


Product to be stripped
Other characteristics

Min.: 10 mm (0 in)

Max.: 30 mm (1 in)


The OUTER ROTARY STRIPPING MACHINE GM ROTAX 30 is a sturdy ELECTROPNEUAMTIC ROTARY CABLE'S STRIPPER that allows the STRIPPING OF ELECTRIC CABLES of considerable size through the rotary movement of two blades mounted on two rotating arms. The setting of the working parameters of the OUTER ROTARY STRIPPING MACHINE GM ROTAX 30 is very simple, such as cable stop jaw distance, blade penetration, stripping lengths, rotation speed and times, all settings are made via touch screen. The OUTER ROTARY STRIPPING MACHINE GM ROTAX 30 is supplied complete with instruction manual, protective guards and CE certification. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - 6 Bar ABSORBIMENT - 200 W STRIPPING LENGTH - 0,1÷150 mm WORKABLE DIAMETER - 10÷30 mm WORKABLE CABLE - PVC-Teflon-Silicon-Similar MIN CABLE LENGTH - 70 mm + Strip TOLERANCE - <= 0,002 xL (L=Stripping Length) DISPLAY - Touch Screen LCD Liquid Cristal Display MEMORY - No WEIGHT - 80 Kg DIMENSIONS - 900x400x420 mm (WxDxH)
